Product Code: 816101
M6 x 1 Long Thread Cup Type 303 Stainless Steel
816101
Description
M6 x 1 Parallel Cup Type Grease Fitting with 7.2mm Long Thread.
303 Grade Stainless Steel (A2 or V2A) Body. 302 Grade Stainless Steel Spring and 440C Grade Stainless Steel Ball.
Ref DIN 3405. (D1)
Additional information
| Angle | Straight |
|---|---|
| Ball Check | Yes |
| Dimension A (mm) | 9.2 |
| Dimension B (mm) | 7.2 |
| Hardened | No |
| Hole | M6 x 1 |
| International | DIN 3405 |
| Product Type | Cup Type |
| Material | 303 Stainless |
| Spanner Wrench Size | 7mm Hexagon |
| Thread | M6 x 1 Parallel |
| Thread Type | Metric |
| Zinc Plating | No |
