1/8英寸 x 27英寸

黄油嘴

1/8″ x 27 PTF (also referred to as NPT, ANPT, American Pipe, Briggs) have a 60° thread form and a 1:16 taper. The full definition is described in SAE J476. There is provision in SAE J534 for extra truncation on the crests of the threads.

The reference 1/8″ does not refer to the diameter of the thread. It is an old reference to the pipe size onto which the thread would be used. The nominal diameter of these threads is roughly 0.4” (approx. 10mm).
The self forming version of this thread has a 90° thread form and a 10° diametral taper.

1 8 X 27 Montage4 Grease Nipple Manufacturer

Quality Grease Nipples, Made in Britain

At Kingfisher Lubrication, we manufacture our full range of grease fittings right here in Britain. From standard grease nipples to custom fittings, every part is made with care, using high-quality materials and strict quality checks.

Keeping our manufacturing in the UK means:

  • Better consistency and reliability

  • Faster turnaround times

  • Easier traceability and accountability

  • Support for British industry and jobs

We don’t cut corners or outsource key parts of the process. Our customers rely on us for products that last—and being made in Britain helps us deliver just that.

Read more
Read LessRead More
A Blue Text On A White Background

1/8" x 27 - Standard Grease Fttings

Below are our most common 1/8″ x 27 fittings. To view the product please click the product code.

翠鸟代码

翠鸟代码

描述

White Trivalent. RoHS, REACH Compliant

Yellow Chromate. Limited Availability

1/8" x 27 PTF Straight

1/8" x 27 PTF 45°

1/8" x 27 PTF 65°

1/8" x 27 PTF 90°

1/8" x 27 1.1/4 Long

1/8" x 27 Self Form Straight

1/8" x 27 Self Form 45°

1/8" x 27 Self Form 90°

Some grease fittings are also available in 303 stainless, 316 stainless & Monel®
请注意：白色三价铬更符合 RoHS 和 REACH 标准。

产品类型

材料

球检查

公制

主题描述

角度选择器

扳手尺寸

推荐洞

螺纹类型

显示较少

Looking for something else? View our full range of grease fittings and other fittings on our dedicated product page 这里.
